• AC motor (3-ph or 1-ph)
  • Cross gears
  • Acme screw or ball screw (VRS)
  • Chrome plated steel push rod
  • Grease lubricated (standard) or oil lubricated (with ball screw, for continuous duty S1)
  • IP 65 tested according to CEI EN 60529 (only for brake motors: standard IP 54, IP 65 on request)
  • Working temperature range: -10° C +60 °C
  • Intermittent duty S3 30% (5 min.) at 30° C (with acme screw)
  • Continuous duty S1 at 30° C (with ball screw)
  • Limit switches, potentiometer and encoder on request
  • At-Ex II 3 D T4 version (AC motor) on request
Technical data

Max force: 18.000 N
Max speed: 113 mm/s
Motor: AC
